Name |
Value |
| 1. |
Main dimension |
| Length overall, m |
202.75 |
| Length on SWL, m |
193.70 |
| Breadth overall (with fenders), m |
27.40 |
| Breadth, m |
27.00 |
| Depth to the main deck, m |
8.60 |
| Depth to the upper deck, m |
15.00 |
| L x B x H |
202.75 x 27.40 x 21.0 = 116 662 |
| 2. |
Draught at SWL, m |
7.0 |
| 3. |
Deadweight at SWL draught (about), t |
18430 |
| 4. |
Range, nautical miles |
3000 |
| 5. |
Endurace: |
by fuel stores,
fresh water and provision stores, days |
10 |
by sewage tanks
(in areas where any discharge are prohibited), days |
3 |
| 6. |
Number of cargo decks |
3 |
| 7. |
Length of rails: |
| upper deck, m |
880 |
| main deck, m |
950 |
| lower deck, m |
340 |
| 8. |
Loading capacity for railway cars: |
cisterns of T-1 gauge with length
between autoreplacers 12020 mm (four-axled), units |
168 |
freight cars of T-1 gauge with length
between autoreplacers 24620 mm (four-axled), units |
82 |
gondola wagon of T-1 gauge with length
between autoreplacers 17670 mm (four-axled), units |
116 |
| 9. |
Lane meters |
2270 |
| 10. |
Loading capacity for vehicles: |
trucks with a semitrailers length 12-13.5 m
(road train 16.5 m) (without railway trains), units |
122 |
| 11. |
Cargo lift |
1 x 188 t |
| 12. |
Passenger capacity: |
| general passenger capacity, pers. |
12 |
| superior single cabins with lavatory and douche, pers. |
4 |
| double cabins with lavatory and douche, pers. |
8 |
| 13. |
Passenger recreation rooms: |
separate dayroom;
internet-cafe (as a part of passengers lobby);
buffet;
dining room;
smoking room |
| 14. |
Additional rooms for passenger service: |
baggage room with
stuffing-discharging convenient |
| 15. |
Sports and fitness complex: |
gym;
sauna;
pool |
| 16. |
Passenger lift |
1 x 3 pers. |
| 17. |
Russian maritime Register of Shipping class |
KM  Arc4 AUT1-ICS OMBO ECO Ro-ro ship |
| 18. |
ME power, kW |
4 x 5220 |
| 19. |
Rudder and propeller complex |
2 x CPP +
2 semibalanced rudders |
| 20. |
Thrusters: |
| bow, kW |
2 x 1000 |
| stern, kW |
1 x 1000 |
| 21. |
Auxiliary engines: |
| diesel-generators, kW |
2 x 1140 |
| shaft generators, kW |
2 x 2400 |
| emergency diesel-generator, kW |
1 x 400 |
| 22. |
Lifeboats |
2 x 42 pers.
one of boat completed as rescue boat |
| 23. |
Inflatable life rafts throw over |
2 x 20 pers. |
| 24. |
Crew and service personal, pers. |
24 |
| 25. |
Ship speed in deep still water for the clean
and recently painted hull at 7.0 m draught
and 85% power of ME, knots |
18 |
