PROJECT RST12C
7875 / 5447 DWT chemical - product tanker
Purpose - sea and mixed (river-sea) carrying of crude oil and petroleum products with density up to 1.015 t/m³, including gasoline without restrictions for flash-point, with ensuring temperature of carrying cargo up to 50°C.
• Methyl alcohol;
• Ethyl tert-butyl ether;
• Ethylene glycol;
• Methyl tert-butyl ether;
• Acetone;
• Ethyl alcohol;
• Isopropyl alcohol;
• Cacium lignosulphonate solution;
• Ethyl acetate;
• Hexane (all isomers);
• Octanol (all isomers);
• Sodium hydroxide solution;
• Toluene;
• Urea/ammonium nitrate solution;
• Xylenes;
• Diethylene glycol.
Simultaneous carriage 2 sorts of cargo is provided.
|
| Name |
Shipyard, building number |
Keel laying date |
Launching date |
Delivery date |
| Lachin |
Baku Shipyard, H110 |
29.06.17 |
21.02.19 |
24.04.20 |
| Kalbajar |
Baku Shipyard, H111 |
09.12.19 |
15.07.20 |
10.09.21 |
| Akademik Khoshbakht Yusifzadeh |
Baku Shipyard, H112 |
21.08.19 |
20.09.21 |
07.12.22 |
| Zangilan |
Baku Shipyard, H113 |
21.05.19 |
16.05.23 |
|
| # |
Name |
Value |
| 1. |
Main dimensions |
| Length overall, m |
141.00 |
| Length between PP, m |
137.10 |
| Breadth overall, m |
16.98 |
| Breadth scantlings, m |
16.90 |
| Depth, m |
6.00 |
| L x B x H |
141.00 x 16.98 x 6.00 = 14 365 |
| 2. |
Draught (in sea (at SWL) / in river), m |
4.54 / 3.60 |
| 3. |
Deadweight (in sea (at SWL) / in river), t |
7875 / 5447 |
| 4. |
Endurance (in sea / river), days |
20 / 12 |
| 5. |
Number of tanks (cargo / slop) |
8 (6 / 2) |
| 6. |
Cargo tanks capacity
(including slop tanks), m³ |
9190 |
| 7. |
Number of manifolds / sorts of cargo |
2 manifolds / 2 sorts |
| 8. |
Cargo pumps, m³/h |
6 x 200 |
| 9. |
Cargo heating |
coils |
| 10. |
Tank wash system and cleaning
of washing liquid |
slop tank's pump output 80 m³/h |
| 11. |
Russian maritime Register of Shipping class |
KM  Ice1 R2-RSN(4.5) AUT1-ICS VCS
ECO-S OMBO Oil tanker/Chemical tanker type 2 (ESP) |
| 12. |
ME power, kW |
2 x 1200 |
| 13. |
Rudder and propeller complex |
2 rudderpropellers |
| 14. |
Bow thruster, kW |
230 |
| 15. |
Auxiliary engines: |
| diesel-generators, kW |
3 x 350 |
| emergency / harbor diesel-generator, kW |
1 x 150 |
| 16. |
Thermal boilers, t/h |
2 x 2.5 |
| 17. |
Crew / berth, pers. |
12 / 14 + pilot |
| 18. |
Speed (at draft d = 4.54 and 100% MCR), knots |
10.0 |
|
