PROJECT PV09
Cruise river-sea diesel-electric passenger vessel
Purpose - trips and cruises by inland waterways and offshore areas of "M-PR" category. Air-draft of vessel makes possible passing under Moscow's bridges.
|
| Name |
Shipyard, building number |
Keel laying date |
Launching date |
Delivery date |
| Shtandart |
Verf' brat'ev Nobel', 100 |
18.03.14 |
25.10.14 |
23.05.17 |
| # |
Name |
Value |
| 1. |
Main dimension |
| Length overall, m |
95.88 |
| Length DWL scantlings, m |
94.30 |
| Breadth overall (with fenders), m |
13.80 |
| Breadth scantlings, m |
13.00 |
| Depth, m |
3.80 |
| L x B x H |
95.88 x 13.80 x 3.80 = 5 028 |
Air draft to an upper edge of non-removable parts
at draught d = 1.80 m, m |
8.80 |
| 2. |
Draught on DWL, m |
1.80 |
| 3. |
Endurance: |
| by fuel stores, days |
10 |
| by provision stores, days |
10 |
by fresh water stores
(fresh water treatment plant with
capacity of 27 m³/day), days |
unconditioned |
| 4. |
Numbers of deckhouse tiers |
3 live +
1 walking |
| 5. |
Passenger capacity, pers. |
36 |
| 6. |
Sports and fitness complex: |
gym;
SPA saloon with sauna, jacuzzi and massage |
| 7. |
Cargo lifts, units |
2 |
| 8. |
Russian River Register class |
 M-PR 2,5 (ice 20) A |
| 9. |
MDG power, kWe |
4 x 830 |
| 10. |
Rudder and propeller complex |
2 x Rudderproppellers |
| 11. |
Bow thruster, kW |
1 x 200 |
| 12. |
Auxiliary/emergency diesel-generator, kWe |
1 x 70 |
| 13. |
Life motor boats |
2 x 6 pers. |
| 14. |
Liferafts |
4 x 16 pers. |
| 15. |
Crew and service personal, pers. |
33 |
| 16. |
Service speed, km/h |
22.5 |
| 17. |
Full speed, km/h |
23.8 |
|
